Product Details:

• Model Number: TBU405 M1
• ACASIS 40Gbps M.2 NVMe SSD Enclosure Compatible with Thunderbolt 3/4, USB 4.0, TBU405 M1
• Technology Upgrade，Lightweight And Portable，Multiple Heat Dissipation
• Dimensions and Weight
• Length: 100 mm
• Width: 61 mm
• Height: 14.5 mm
• Weight: 95 g
• Color：Silver/Dark Grey
• Material：Aluminum alloy
• SSD Capacity: Up o 8TB
• Transmission Speed：40Gbps (Theoretical speed)
• Dual Chip：Intel® JHL7440 Thunderbolt™3 with REALTEK® RTL9210B
• Hardware Interface：Thunderbolt
• USB Interface：Thunderbolt /Type-c
• USB Specification：USB4.0（Downward compatible with USB2.0 ）
• Compatibility：M Key & (M+B) Key
• Compatible Systems：Windows / Mac / Linux
• What’s in the box ：
• 40Gbps Nvme Enclosure*1，0.5M Thunderbolt 4 Cable*1, 0.5mmThermal pad*2，User Manual*1

Warm Tips:

• Please make sure your SSD is 22x80mm M.2 NVME with M key or B+M key before purchase
• Please make sure your computer has a Thunderbolt interface.
• Recommend SSD is: Samsung 980 pro SSD for better speed experience.

Product Description:

【Lightning-Speed Data Transfer】The ACASIS M.2 NVMe Aluminum Enclosure fully supports Thunderbolt 3/4 for transmission speed up to 40Gbps, transforming your computer into a workstation handling multi-terabytes of data easily.

【Reliable Performance】ACASIS has carried out numerous speed tests to ensure performance of this enclosure and offer customers viable advice.

【Excellent Heat Dissipation】Aluminum shell, thermal pad and corrugated surface work together to maximize heat dissipation effect, protecting the SSD from overheating while reducing power consumption.

【SSD Compatibility】Support M-key & B+M key PCIe NVMe SSDs (size: 22*80), highly recommend Samsung 980 PRO which has the best speed on most of the devices.

【Compact and Portable】This NVMe enclosure is compact (3.97×2.04×0.53in) and lightweight (95.25 gm) to be carried everywhere easily for daily work or business travel.

【Plug and Play】Compatible with Windows, macOS and Linux. Just plug and play without a driver. It supports hot-swapping without affecting the rest of the server’s capabilities.

【Performance Reference】This chart will offer you read/write speed reference of frequently-used SSDs with different Mac devices.

FAQ

Q1: Best Speed Reported Here is 2800 MBytes/s --- that's equal to 22.4 Gbps -- Is it a Rip-Off?

No it’s not a rip off. 40 is Theoretical Speed, TB3 or TB4 actual speeds are at around 2500-2800 MBytes/s

Q2: Why Can't Reach Maximum Speed?

In any case, it needs to Reserve at least 18Gbps of available bandwidth for DP Signals, and it has the priority of allocating the remaining bandwidth. CERTAIN PERFORMANCE LOSS WAS BOUND TO OCCUR IN THE PROCESS OF DATA EXCHANGE.

Q3: What is the Difference Between Acasis Tbu401 & Tbu405 M1?

TBU405 M1 has BETTER HEAT DISSIPATION and SMALLER SIZE Than TBU401. AN UPGRAD VESION OF TBU401

Q4: Does this come with thermal pad？

Yes.
