Gopichandan Stick making machine

Power rating		1 HP
Supply power to machine

Power rating		1 HP
Supply power to machine		220 V AC Single phase
Motor		1 Phase x 1 HP x 1440 RPM
AC Drive		1 HP std make with Enclosure panel and accessories
Gearbox		Aluminium Die cast body with worm reduction
Gearbox Ration		50 1 with reduction
Maximum speed of screw		30 RPM
MOC process contact		SS-304
Extrusion Die		2 nos (As per your specifications)
Extruder screw Size		80 NB x 300 Long Aproximate
Machine Frame		MS powder coated with wheel and locking system
Processing Capacity		About 40 Kg per hour
Maximum Volumetric capacity		About 55 litres per hour

Country of origin	India
Brand	Engivative
Common name	Gopichandan stick making machine
Net Quantity	1 unit
Included items	Cold Extrusion machine with MS powder coated base plate, 1 HP motor single phase with two extrusion die as per client specifications.
Batch number	Tailor Made
Expiry Date	Not Applicable
Package Dimension	130L x 30W x 60H cm
Product Dimensions	130L x 40W x 60H cm
Manufacturer or packer name	Prayosha Innovative
Manufacturer or packer address	2226, Shradha Housing Society, Near Ambikanagar. Gotri. Vadodara 390021. Gujarat
Manufacturing Date	11/2023
Storage conditions	Dry and away from wet surfaces
contact details consumer care	Prayosha Innovative, [email protected]
